This wooden handle making machine is belong to wood round stick processing equipment.

This wooden handle making machine is belong to wood round stick processing equipment.

The machine is mainly make long strips bamboo or wood material and round wood into round sticks and smooth square sticks.The final produce most used to make broom handle,shovel handle ect.The machine can be customized according to your wood handle diameter.

Feature:

1.The proper material is widely,such as elongated wood and round stock embryo,to change the disadvantage of raw material limited.

2.Smooth surface,the stick which processed approach to the one through sanding,to leave the sanding process by changing the speed of the machine .

3.High efficiency, the highest speed of the machine can reach 25 pcs/min,and can be customed the machine which can process more sticks for one time

Technical Data

Model	GG-9020	GG-9020A
Drawing-enroller	Single Feeding&Single Discharging	Double Feeding&Single Discharging
Main motor power	2.2kw	2.2kw
Feeding motor power	0.55kw	0.55kw
Spindle velocity	5000r/min	5000r/min
Feeding speed	3/5m/min	3/5m/min
Finished Rod diameter	6-20mm	6-20mm
Max.cutting quantity	1(semi-diameter)mm	1(semi-diameter)mm
Min.working length	300mm	300mm
Overall dimension	720560820mm	870560820mm
Machine weight	170kg	190kg
